Face Mask Single Core Double Core Nose Wire Cable Extrusion Production Line

Brand Name : I-suntop

Model Number : I-35/45/60

Certification : SGS

Place of Origin : China

MOQ : 1set

Price : By negotiation

Payment Terms : L/C,T/T

Supply Ability : Up to different machine

Delivery Time : Min.50working days

Packaging Details : Plastic film+wooden box

Application : Extruding for nose wire

Extrusion Material : PVC/PE

Screw Dia Meter : 35/45/60mm

Voltage : 3phase 380V 50HZ/60HZ

Warranty : 18month

After-sales service provided : Engineers available to service machinery overseas

Contact Now

Face Mask Single Core Double Core Nose Wire Cable Extrusion Production Line

i-suntop Electric wire and cable equipments2022022...

1. Specification for Face Mask Single Core Double Core Nose Wire Cable Extrusion Production Line :

  • Installation power: 36kw, Actual consumption electricity consumption 60~70%
  • Material: PP or PE or pvc granual
  • Machine Dimension: 13*2*2.5m
  • Product Dimension: diameter: 3.5-10.0mm
  • Manpower: 1-2 persons required to operate whole plant
  • Mould Design: one-in-one type, two-in-one type
  • with metal/without metal

2. Main paramters for Face Mask Single Core Double Core Nose Wire Cable Extrusion Production Line :

item model motor power capacity
1 GF35 3kw/5.5KW 8-12KGS/H
2 GF45 7.5KW/11KW 20KGS/H
3 GF60 15KW /18.5KW 60-80KGS/H

3. Main items for Face Mask Single Core Double Core Nose Wire Cable Extrusion Production Line :

No Machine name Q'ty
1 Steel wire unwinding and straigtening system 1 set
2 Single Screw Extruder with automatic material loading and drying machine 1 set
3 Mould 1 set
4 Water cooling tank I 1 set
5 Water cooling tank II 1 set
6 Haul-off machine 1 set
7 filament storage with accumulator- 1 set
8 double Winding Machine 1 set

Face Mask Single Core Double Core Nose Wire Cable Extrusion Production Line
